Screw and Barrel Weber DS88
Kingz Machinery is specialized at high quality screw barrels, such as Screw and barrel DS88, screw and barrel Weber DS88, screw and barrel for Weber DS88 twin screw extruder
Weber DS88
Twin screw extruder
Screw diameter 88mm
LD 17/1
Technical specification:
Screw’s and barrel’s material: high quality alloy steel: 38CrMoAlA;
At material outlet section: with hard alloy slots. Slot length: 300mm
Process: advanced nitriding process
Hardness after Hardening & Tempering: HB280-320
Nitrided hardness: HV900-1000(HV940=HRC68)
Nitrided case Depth:0.45-0.8mm
Nitrided brittleness: Less than Grade 2
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy hardness: HRC 50-65
Alloy depth:0.8-2.0mm
Packing size: 1980*395*455mm
Gross weight: 412kg.
